Personal Home Support Centre Device Guides OPPO R15 Pro Messaging & email I can't send and receive picture messages

OPPO R15 Pro

Android 8.1
Back to section Messaging & email

I can't send and receive picture messages

Your phone hasn't been correctly set up for picture messaging

Set up your phone for picture messaging

Press Settings.
Press Dual SIM & Mobile.
Press the required SIM.
Press Access Point Name.
Press the new data connection icon.
Press Name.
Key in Telstra MMS and press Save.
Telstra MMS
Press APN.
Key in telstra.mms and press Save.
telstra.mms
Press MMSC.
Key in http://mmsc.telstra.com:8002 and press Save.
http://mmsc.telstra.com:8002
Press MMS Proxy.
Key in 10.1.1.180 and press Save.
10.1.1.180
Press MMS Port.
Key in 80 and press Save.
80
Press MCC.
Key in 505 and press Save.
505
Press MNC.
Key in 01 and press Save.
01
Press Authentication Type.
Press None.
Press APN Type.
Key in mms and press Save.
mms
Press Save.
Press the Home key to return to the home screen.
  • 1
    Find "Access Point Name"
    • Press Settings.
    • Press Dual SIM & Mobile.
    • Press the required SIM.
    • Press Access Point Name.
  • 2
    Create new data connection
    • Press the new data connection icon.
  • 3
    Enter a name for the connection
    • Press Name.
    • Key in Telstra MMS and press Save.
  • 4
    Enter APN
    • Press APN.
    • Key in telstra.mms and press Save.
  • 5
    Enter picture messaging server
    • Press MMSC.
    • Key in http://mmsc.telstra.com:8002 and press Save.
  • 6
    Enter IP address
    • Press MMS Proxy.
    • Key in 10.1.1.180 and press Save.
  • 7
    Enter port number
    • Press MMS Port.
    • Key in 80 and press Save.
  • 8
    Enter country code
    • Press MCC.
    • Key in 505 and press Save.
  • 9
    Enter network code
    • Press MNC.
    • Key in 01 and press Save.
  • 10
    Select authentication type
    • Press Authentication Type.
    • Press None.
  • 11
    Enter APN type
    • Press APN Type.
    • Key in mms and press Save.
  • 12
    Save data connection
    • Press Save.
  • 13
    Return to the home screen
    • Press the Home key to return to the home screen.

Did this solve your problem?

Yes
No
The picture message isn't written correctly
Mobile data is turned off
Data roaming is turned off
There's an error at the receiving end

Can you make a voice call?

It's important to find out if you can make a voice call. If you can't make a voice call, you need to solve this problem first. When the problem is solved, you will most likely also be able to send and receive picture messages.

No
